The AR45 Plumbing Kit gives you everything you need to connect your AR45 pump to your tanks, hose reel, and bypass line. If you’re running an AR45 pump, this kit makes your setup much easier by saving you from tracking down every part separately. Each hose and fitting is sized specifically for the AR45, so you can get a clean install that keeps your system running smooth.
Built with stainless steel and poly components, this kit is tough enough to handle soft wash chemicals and daily use. It’s a complete solution designed to help you spend less time piecing together plumbing and more time working jobs.
What’s Included
-
2 x 1” bulkheads
-
6 x 1” stainless steel hose clamps
-
2 x 3/4” stainless steel hose clamps
-
2 x 1/2” stainless steel hose clamps
-
1 x 1/4” stainless steel hose clamp
- 2 x 1 1/4" stainless steel hose clamps
-
1 x 1/2” stainless steel hose barb
- 2 x 1" stainless steel hose barbs
-
2 x 1” poly hose barb elbows
-
1 x 1” canister filter
-
10 ft x 1/4” soap input hose
-
10 ft x 1/2” outlet hose (pump to hose reel)
-
25 ft x 3/4” bypass hose
-
30 ft x 1” input hose (water and SH)
-
10 ft x 1 1/4” AR45 intake hose (proportioner to pump)
-
2 x 1” MNPT by 1” slip fittings (for drop tubes in water and SH tank)
**Drop tubes are not included and must be purchased separately.
Key Features
-
Built for AR45 pumps: Every part is sized specifically for the AR45, so you get a direct fit with no guesswork.
-
Made for proportioner setups: All hoses and fittings are matched for a clean and reliable proportioner connection.
-
Durable materials : Stainless steel and poly parts are built to hold up against soft wash chemicals and everyday wear.
-
All-in-one solution: Instead of buying parts separately, you get the complete plumbing setup in one kit.
-
Cleaner, safer setup: The included canister filter and proper fittings help protect your pump and reduce the risk of leaks.
-
Time-saving install: With everything ready to go, you’ll spend less time figuring out plumbing and more time on the job.
Why do you need an AR45 Plumbing Kit?
Setting up an AR45 pump is easier when you start with the right plumbing. Instead of hunting for parts, this kit gives you everything in one place so you can hook up your system without the guesswork. The durable parts are built to last, and since each hose and fitting is sized for the AR45, you get a clean install that works the first time.
